Idemia MorphoWave Compact - Default Chapter; Table of Contents

5
MorphoWave Compact - 2018_2000035853
Table of content
1 / Introduction 8
1.1 > MorphoWave Compact terminal 9
1.2 > Scope of the document 10
1.3 > Safety Instructions 11
1.4 > Wiring Recommendations 12
1.5 > Regulatory, safety and Environmental notices 13
1.5.1 > European Union (CE) regulatory notices 13
1.5.2 > USA (FCC) regulatory notices 14
1.5.3 > Canada (IC) regulatory notices 15
1.6 > Others recommendations 16
1.7 > Recommendations for terminal implementation 17
2 / General description 20
2.1 > Box opening 21
2.2 > Components of the initial package 22
2.3 > Terminal's front view description 23
2.4 > Terminal's rear view description 24
2.5 > MorphoWave Compact Technical Characteristics 25
3 / Installation procedure 28
3.1 > Before proceeding to the installation 29
3.2 > Installation 30
3.3 > Step by step procedure 31
3.3.1 > Drill the mounting holes 32
3.3.2 > Make the connections 33
3.3.3 > Attach the base plate on the wall 35
3.3.4 > Attach the device on the base plate 36
3.3.5 > Connect the connector assembly on the device 37
3.3.6 > Close the device on the base plate 38
4 / Electrical interface 40
4.1 > Wiring overview 41
4.2 > Power Supply 42
