PoE+ (Power over Ethernet Plus)
MorphoWave Compact terminal's power supply can also be provided by the Ethernet using RJ45 connection
(Power over Ethernet Plus mode - IEEE802.3at type 2 compliant).
The terminal may be powered via a UL 294B PSE PoE+ Limited power source with a range of 48VDC (-
10% /+15%). UL 294 compliance was verified with PoE+ (PSE-Power Sourcing Equipment manufacturer
Microsemi, part number PowerDsine 9501G).
If several terminals are powered through the same PoE+ switch, make sure the switch is
capable of providing enough power to each device (25W).
Some functions are available ONLY with an external and not with PoE power supply: Wi-
Fi, SAM, PIV/TWIC. External DC power is required for these features.
