4.9 > Ethernet connection
Use a category 6 shielding cable (120 Ohms) or better. It is strongly recommended to insert a repeater
unit every 90 m.
Recommendations for RJ45 wiring
Pin
1
2
3
4
5
6
7
8
Signals
Data
pair 1
Data
pair 1
Data
pair 2
NC/POE
pin
dedicated
(+)
NC/POE
pin
dedicated
(+)
Data
pair 2
Ground/
pin
dedicated
(-)
NC/POE
pin
dedicated
(-)
EIA / TIA T568B
Colors
White
orange
Orange
White
green
Blue
White blue
Green
White
brown
Brown
EIA / TIA T568A
Colors
White
green
White
green
White
green
White
green
White
green
White
green
White
green
White
green
Corel L120
Colors
Grey
White
Pink
Orange
Yellow
Blue
Purple
Brown
Figure 22: RJ45 wiring
RJ45 plug pinout is compliant with 10/100 base T, IEEE802.3 Specification. Product is compliant also with
MDI or MDI-X.
Ethernet cable shall be shielded
Ethernet interface can be used to power the MorphoWave Compact terminal through PoE+ (Power Over
Ethernet Plus - IEEE802.3at type 2 mode). According to the PoE+ standard two modes are available:
power on data pins and power on dedicated pins.
Use either one of these modes depending on PoE+ implementation on your local Ethernet network.
Some functions are available ONLY with an external and not with PoE power supply: Wi-
Fi, SAM, PIV/TWIC. External DC power is required for these features.
Default Ethernet configuration
By default, MorphoWave Compact terminal is configured in STATIC mode with the following configuration:
IP Adress : 192.168.1.10; Gateway Adress : 192.168.1.254; Subnet Mask : 255.255.254.0
