Reference Manual for uTrust 4701F and uTrust 4711F Readers
4.2.2. LED behavior
uTrust 47x1 F is equipped with one bicolor LED. Its behavior is described in the table below.
Reader states
GREEN
RED
Just after plug-in (with
drivers already installed)
ON
OFF
Just after DFU operation
ON
OFF
Suspend / standby
OFF
OFF
Reader powered, Contact
card IN, but not powered
ON
OFF
Reader powered,
Contactless card IN, but not
powered
ON
ON
Contact card powered /
communication
500ms ON
500ms OFF
OFF
Contactless card powered /
communication
500ms ON
500ms OFF
500ms ON
500ms OFF
Reader / card errors
OFF
100ms ON
100ms OFF
Dual interface card
powered in contact Slot
500ms ON
500ms OFF
OFF
Dual interface card
powered using RF field
500ms ON
500ms OFF
500ms ON
500ms OFF
4.2.3. Other data
4.2.3.1. General
Parameter
Value/Description
Clock of the device controller
8MHz
API
PC/SC 2.0
Operating temperature range
0º to 50ºC
Operating humidity range
Up to 95%RH non condensing
Certifications and compliances
USB, CE, FCC, WHQL, WEEE, RoHS2, REACH
