Reference Manual for uTrust 4701F and uTrust 4711F Readers
6.3.4.12. CNTLESS_FORCE_BAUDRATE
This escape command can be used to restrict the baud rate for contactless cards to certain values.
The input buffer is
Byte #
Value
Description
B0
0xAD
Escape command code
B1
0x00
Use the baud rate specified by the card
0x01
Only allow baud rates specified in B2
B2
b0- DR=2 supported, if bit is set to 1
b1- DR=4 supported, if bit is set to 1
b2- DR=8 supported, if bit is set to 1
b3- shall be set to 0, 1 is RFU
b4- DS=2 supported, if bit is set to 1
b5- DS=4 supported, if bit is set to 1
b6- DS=8 supported, if bit is set to 1
b7- 1 if the same D is required for both
communication directions
b7- 0 if different D is supported for
each communication direction
Encoding of the baud rate to be allowed if
B1 value is 0x01. No need to send this byte
in case B1 has the value =x00
NULL
If B1=0x00
The output buffer is
Output buffer
NULL
6.3.4.13. CNTLESS_GET_CARD_DETAILS
This Escape command is used to get details about the PICC placed in the field of the reader.
Input:
The first byte of input buffer contains the escape code.
Byte0
Escape code(0xDA)
Output:
Byte #
Value
Description
B0
0x00
Type A card
0x01
Type B card
0x04
FeliCa 212
0x08
FeliCa 424
B1
0x00
Memory card
0x01
T-CL card
0x02
Dual interface card
