5. Software modules
5.1. Installation
On Operating Systems with a CCID driver pre-installed, no installation is necessary.
Where there’s no CCID driver pre-installed – e.g. Linux systems or old Windows systems – the driver
has to be installed using distribution-specific measures or using the available source packages.
Nevertheless, due to some limitations of the available CCID drivers under some circumstances, Identiv
does provide a dedicated driver for this reader, as well, which is available through Windows Update
or on the Identiv support pages.
5.2. Utilities
The following utilities are available:
● A tool for testing the resource manager
● A tool called PCSCDiag capable of providing basic information about the reader and a card
through PC/SC stack
5.3. Driver
5.3.1. uTrust 47xx F listing
uTrust 47XX F is listed by PC/SC applications as
● Identiv uTrust 47xx F Contact Reader
● Identiv uTrust 47xx F Contactless Reader
5.3.2. Supported operating systems
● Windows Server 2012, 2016 (32 & 64 bit)
● Windows 7 (32 & 64 bit)
● Windows 8.1 (32 & 64 bit)
● Windows 10 (32 & 64 bit)
● macOS 10.12, 10.13
● Linux 3.x (32 & 64 bit)
5.3.3. PC/SC 2.0 compliant ATR for contactless interface
When a user credential is placed on the reader, initialization, anti-collision is done. The user credential
is automatically activated and an ATR is built as defined in the PC/SC specification. For further
information, please refer to section 3.1.3.2.3 of [PCSC3] and to [PCSC3-SUP].
