Example:
1) To issue the “READER_GETIFDTYPE (0x12)” escape command , this pseudo APDU would be
used:
Command APDU: FF CC 00 00 01 12
Response : 20 57 90 00
2) To issue the “READER_SETMODE (0X01)” escape command, this pseudo APDU would be
used:
Command APDU: FF CC 00 00 02 01 01 (to set to EMV mode)
Response APDU : 90 00
Note:
1) To send Escape commands using this method, the reader should be connected in shared mode
using T0 or T1 protocol. Only then would the resource manager allow SCardTransmit.
2) As the escape commands defined using “READER_GENERIC_ESCAPE” have ISO 7816 APDU
format, they can be sent using SCardTransmit without having any need to prepend “FF CC 00
00 P3”.
