Moving the Machine – Reference point out of reach of the bucket tip
126
• Setup the rotating laser.
• Measure the elevation difference between the laser plane and the reference
point.
• In this example, the elevation difference to the reference point is 3’, PLUS 6’
elevation difference to the ground, makes a total of 9’.
3‘
6‘
