[Format] ASCII ESC 2
Hex 1B 32
Decimal 27 50
[Description] Selects 3.75mm line spacing.
[Details] •The line spacing can be set independently in standard mode and in page mode.
[Reference] ESC 3
17. ESC 3 n
[Name] Set line spacing
[Format] ASCII ESC 3 n
Hex 1B 33 n
Decimal 27 51 n
[Range] 0 ≤ n ≤ 255
[Description] Sets the line spacing to [ n
╳
vertical or horizontal motion unit] inches.
[Details] • The line spacing can be set independently in standard mode and in page mode.
• The horizontal and vertical motion unit are specified by GS P. Changing the
horizontal or vertical motion unit does not affect the current line spacing.
• The GS P command can change the horizontal (and vertical) motion unit.
However, the value cannot be less than the minimum vertical movement
amount, and it must be in even units of the minimum vertical movement
• In standard mode, the vertical motion unit (y) is used.
• In page mode, this command functions as follows, depending on the starting
position of the printable area:
① When the starting position is set to the upper left or lower right of the
printable area using ESC T, the vertical motion unit (y) is used.
② When the starting position is set to the upper right or lower left of the print
able area using ESC T, the horizontal motion unit ( x) is used.
• The maximum paper feed amount is 956mm . Even if a paper feed amount of
more than 956mm is set, the printer feeds the
[Default] Line spacing equivalent to approximately 3.75mm.
[Reference] ESC 2, GS P
18. ESC = n
[Name] Choose printer
[Format] ASCII ESC = n
Hex 1B 3D n
Decimal 27 61 n
[Range] 0 ≤ n ≤ 1
[Description] Selects device to which host computer sends data, using n as follows:
Bit
1/0
Hex Decimal Function
0
0 00 0 Printer disabled
1 01 1 Printer enabled
1-7 - - - Undefined
[Details] When the printer is disabled, it ignores all data except for error-recovery commands
(DLE EOT, DLE ENQ, DLE DC4).
