Commands using x: ESC 3, ESC J, ESC W, GS $, GS \
Commands using y: ESC SP, ESC $, ESC W, ESC \,FS S, GS V
The command does not affect the previously specified values.
The calculated result from combining this command with others is truncated to
the minimum value of the mechanical pitch.
[Default] x = 200, y = 200, horizontal 1/8mm, vertical 1/7mm。
[Reference] ESC SP, ESC $, ESC 3, ESC J, ESC W, ESC \, GS $, GS L, GS V, GS W, GS \
53. ①GS V m ②GS V m n
[Name] Select cut mode and cut paper
[Format] ①ASCII GS V m
Hex 1D 56 m
Decimal 29 86 m
②ASCII GS V m n
Hex 1D 56 m n
Decimal 29 86 m n
[Range] ① m =0, 48, 1,49
② m = 66, 0 ≤ n ≤ 255
[Description] Selects a mode for cutting paper and executes paper cutting. The value of m
selects the mode as follows:
m Print mode
0, 48 Full cut
1, 49 Partial cut
66
Feeds paper (cutting position + [ n
╳
(vertical motion unit)]), and cuts the paper in
partial
[Note]
• This command is effective only processed at the beginning of a line.
• When m = 0, 48, 1, 49, the printer cut paper directly.
• When n = 66, the printer feeds the paper to (cutting position + [ nX vertical
motion unit]) and cuts it.
• The horizontal and vertical motion unit are specified by GS P.
• The paper feed amount is calculated using the vertical motion unit (y).
54. GS W nL nH
[Name] Set printing area width
[Format] ASCII GS W nL nH
Hex 1D 57 nL nH
Decimal 29 87 nL nH
[Range] 0 ≤ nL ≤ 255
0 ≤ nH ≤ 255
