38. ESC p m t1 t2
[Name] Generate pulse
[Format] ASCII ESC p m t1 t2
Hex 1B 70 m t1 t2
Decimal 27 112 m t1 t2
[Range] m = 0, 1, 48, 49
0 ≤ t1 ≤ 255, 0≤ t2 ≤ 255
[Description] Outputs the pulse specified by t1 and t2 to connector pin m as follows:
m Connector pin
0, 48 Drawer kick-out connector pin 2.
1, 49 Drawer kick-out connector pin 5.
[Details] • The pulse ON time is [ t1
╳
2 ms] and the OFF time is [ t2
╳
2 ms].
• If t2 < t1, the OFF time is [ t1x 2 ms]
[Reference] DLE DC4
39. ESC t n
[Name] Select character code table
[Format] ASCII ESC t n
Hex 1B 74 n
Decimal 27 116 n
[Range] 0 ≤
n ≤
, 16 ≤
n ≤
19
[Description] Selects a page n from the character code table.
n Page
0 PC437 [U.S.A.Standard Europe]
1 Katakana
2 PC850:Multilingual
3 PC860:Portuguese
4 PC863 [Canadian French]
5 PC865:Nodic
6 West Europe
7 Greek
8 Hebrew
9 PC755:East Europe
10 Iran
16 WPC1252
17 PC866:Cyrillic#2
18 PC852:Latin2
19 PC858
20 IranII
21 Latvian
[Default] n = 0
