Part 1 - Remote Setup
32
• Motion Ignoring Interval: With Motion Ignoring
Interval congured, no event log or notication is
generated for motions detected during a period of
time following a motion detection event.
• Daytime: Specify when daytime starts and ends. All
other times will be assumed as nighttime.
• Use Ignoring Time: Dene the event ignoring time.
Motion detections taking place during the dened
time range will not be assumed as events.
DC-
D6233HRX, DC-D6243HRX only
• Event Action: Select a motion detection event alert
action.
- Alarm Out: Select if you wish to generate an alarm
out.
- Send Email: Select if you wish to send an email.
Select the Image Attachment option to attach a
.jpg image of the event detected to the email.
- Remote Callback: Select this option to send a
message to a remote system and then select which
system to send the message to.
• Not supported from the IDIS Web program.
• The camera must be registered to the remote
system in order to use the Remote Callback
feature.
- Audio Alarm: Select this option to generate an
audio alert and then choose an audio le.
- FTP Upload: Select this option if you wish to
upload images to the FTP server.
- Record: Select this option to record video.
Event Action settings must be congured correctly
in order to perform event actions.
Trip-Zone
Select Trip-Zone to congure trip zone event settings.
With trip zone event enabled, motion of the objects
detected inside/outside the selected area will be
assumed as an event.
DC-D3233HRX-N, DC-D3243HRX-N
DC-D6233HRX, DC-D6243HRX
• Sensitivity: Select daytime and nighttime motion
detection sensitivity levels. Higher values will result
in more sensitive motion detection.
DC-D3233HRX-N,
DC-D3243HRX-N only
• Trip-Zone: Click Setup and dene the trip zone using
blocks.
-
(Draw)/ (Erase): Enable/disable trip zone
blocks.
-
(Cell): Select/unselect trip zone blocks
individually.
