IDS 816 Installer Manual

IDS 816 700-283-02I Issued September 2009
16
Table 1 : Values Represented by Each Zone LED
Zone LED
Value
Digit
Zone LED
Value
Digit
Zone 1 1
Units
Zone 9 1
Hundreds
Zone 2 2 Zone 10 2
Zone 3 4 Zone 11 4
Zone 4
8
Zone 12
8
Zone 5
1
Tens
Zone 13
1
Thousands
Zone 6
2
Zone 14
2
Zone 7 4 Zone 15 4
Zone 8 8 Zone 16 8
Example:
Assume the following zone indicators are on:
Zone 1, Zone 3 and Zone 5.
Units are represented by the sum of Zone 1 and Zone 3 (i.e. 1 + 4) and tens of units are represented by
the value of Zone 5 (i.e. 1)
Thus, the value indicated by the LED’s that are on will be shown below.
Zone LED
Value
Digit
Zone 1 1
Units
Zone 2
2
Zone 3
4
Zone 4
4
Zone 5 1
Tens
Zone 6 2
Zone 7 4
Zone 8 8
Therefore, the displayed value is 15.
7. Programming the Panel
For all programming procedures, the [*] star key functions as the <ENTER> key and the [#] hash key
functions as a <CLEAR> or an <EXIT> program key.
Invalid data entries are indicated by means of an error beep consisting of 3 short beeps of the
keypad buzzer.
There are two location categories:
 Standard locations which are single tiered and do not contain any sub-locations.
 Extended locations, which are double tiered and have sub-locations.
Both standard and extended locations may contain further subcategories referred to as bitmapped
locations.
For both main categories, clear visual keypad prompts are provided which aid the
programming process.
