IDS 816 Installer Manual

IDS 816 700-283-02I Issued September 2009
41
Data entered
Explanation
[INSTALLER CODE][*] To enter program mode
[1][2][1][*] To enter location 121 (phone number 1)
[MODE][0] To dial the zero
[MODE][5] This programmes the 4 second pause
[MODE][0][3][1] This programmes the area code
[7][MODE][0][5][1][3][7][3]
The remainder of the number
[0]
To mark the end of the number
[#] To exit program mode
11.2 Telephone Number Storage Locations
LOCATION 121 Phone Number 1
This location contains the primary telephone number. A maximum of 24 digits can be entered. Enter the
digits consecutively and after the last digit has been entered, terminate with a [0].
LOCATION 122 Phone Number 2
This location contains the secondary telephone number. A maximum of
24 digits can be entered. Enter the digits consecutively and after the last digit has been entered,
terminate with a [0].
11.3 Download Options
LOCATION 123
Download Options
LED
ON / OFF
Action
1
ON
Enable fax defeat
OFF
Disable fax defeat
2
ON
Enable forced answer
OFF Disable forced answer
3
ON Enable auto pickup
OFF Disable auto pickup
4
ON Enable call-back
OFF Disable call-back
Default values are shaded
Fax defeat is useful for downloading when a fax or answering machine is connected to the same phone
line as the alarm panel. If this feature is enabled, dial the panel and hang up before three rings. Dial the
panel again within one minute. The panel will then pick up the call on the first ring thereby preventing the
fax / answering machine from answering the call before the alarm.
If forced answer is enabled the [8] key may be used to force the panel to go off hook,
“answering the line”.
If enabled, Auto Pickup will pick up the line after the number of rings programmed into location
124.
The Call-back feature when enabled, allows the download software/PC to request that the
panel call it back using the phone number as programmed into location 125.
