IDS 816

IDS 816 700-283-02I Issued September 2009
40
LOCATION 120 Global Group Reporting Code / Disable 3
LED
ON / OFF
Action
1
ON Enable RF jamming
OFF
Disable RF jamming
2
ON
Enable RF jamming restore
OFF
Disable RF jamming restore
3
ON
RESERVED
OFF
4
ON
RESERVED
OFF
5
ON
RESERVED
OFF
6
ON
RESERVED
OFF
7
ON
RESERVED
OFF
8
ON
RESERVED
OFF
9
ON
RESERVED
OFF
Default values are shaded
11.1 Programming Telephone Numbers
For the telephone number locations, a value of [0] is used as a termination digit. It is important therefore
that any zeros (0) in the telephone number itself be entered as a [10]. All hexadecimal values are entered
using the mode key (See table 2, page 17).
Enter numbers consecutively with no other key presses between each digit.
To dial a “0” program a table 2 [10] – by pressing [MODE] [0]
To dial a “*” program an [11] - by pressing [MODE] [1]
To dial a "#" program a [12] - by pressing [MODE] [2]
Inserting pauses
A pause may be inserted at any point within the telephone number: Entering a value of [13] (by pressing
[MODE] [3]) will provide a 12-second pause and a value of [15] (by pressing [MODE] [5]) will provide
a 4-second pause.
To terminate a telephone number, program a [0] immediately after the last digit of the telephone number.
Example:
Phone number 1 is to be dialled as follows:
[0] followed by a 4 second pause then [0317051373]. The key sequences are as follows:
