IDS 816 Installer Manual

IDS 816 700-283-02I Issued September 2009
23
7.6.2 System Options
LOCATION 33 Zone Shutdown Count (Default = 5)
Determines the number of times a zone may be violated during an arm cycle before it is automatically
bypassed. Select zones individually for this option in locations 1 – 16 (sub-location 2). Valid range of data
for this location is 1 to 15.
LOCATION 34 Programmable Zone Loop Response Time
The following applies when option 4 in location 38, is ON
Value
Response Time
Value
Response Time
0
6 ms
8
96 ms
1 12 ms
9 108 ms
2 24 ms (default)
10 120 ms
3 36 ms
11 132 ms
4
48 ms
12
144 ms
5 60 ms
13 156 ms
6 72 ms
14 168 ms
7
48 ms
15
180 ms
The zone loop response is the period of time for which the programmed zone must remain violated
before a violation is registered. By default, this table is ignored and a Fixed Zone Loop Response of
100ms is used.
LOCATION 35 Reserved
LOCATION 36 Cross-zone Delay Timer
This location defines the cross-zone delay timer period.
Value
Response Time
0 3 seconds
1 10 seconds
2 15 seconds
3 20 seconds (default)
4 25 seconds
5 30 seconds
6 45 seconds
7 1 Minute
LOCATION 37
Cross-zone Count (Default = 2)
If the panel is armed and the total number of violations of zones programmed as cross-zones reaches
this count within the time period programmed into location 36, an alarm condition will be registered.
Program a value from [0] to [1] [5]. A [0] will disable this location. Program zones as cross-zones in sub-
location 2 of locations 1 to 16. Any single zone enabled for cross-zoning, which is violated continuously
for the time specified in location 36 will also register an alarm condition.
