IDS 816 700-283-02I Issued September 2009

Sub-location 3 Alarm Reporting Code

This is the code transmitted when the zone is violated during an arm cycle or if a panic or 24 Hour Zone

is violated.

Sub -location 4 Alarm Restoral Reporting Code

The zone restoral code is transmitted when the zone has returned to the “unviolated” condition after

triggering an alarm.

Sub-location 5 Bypass Reporting Code

A zone bypass code will be reported when a zone has been bypassed and the panel is armed.

Sub-location 6 Force Arm Reporting Code

This code will be transmitted if a partition is programmed to allow forced arming (arming with a violated

zone) and a zone is violated at the time of arming.

Sub-location 7 Tamper Reporting Code

The tamper code will be reported if tamper-by-zone has been enabled and a zone tamper occurs.

Sub-location 8 Tamper Restore Reporting Code

When a zone tamper condition clears, this code will be reported.

Sub-location 9 Swinger Shutdown Reporting Code

The swinger shutdown zone code will be reported if the system is armed and a zone is automatically

bypassed as a result of multiple violations of that zone.

Sub-location 10 Swinger Shutdown Restore Reporting Code

If enabled, this code will be reported when a swinger shutdown zone is automatically restored i.e. un-

bypassed.

Sub-location 11 Zone Programmable Output Location

A programmable output will be pulsed or latched, high or low if a zone causes an alarm condition. If

pulsed, the output will be pulsed for the time programmed in sub-location 1 of locations 388 - 394.

Two digits must be programmed for each zone. The first digit references the programmable

output number e.g. output 1 to 5 (7 with an expander). The second digit sets the output action. Refer

“

System Programmable Outputs” (Page 30) for a detailed description on Programming Programmable

Outputs.

Sub-location 12 Zone Name Editing (LCD keypads only)

Zones may be given appropriate names, like “Front Door” for zone 1, etc. When the zone is triggered, the

display will indicate “Front Door”, instead of “Zone 1”. (Full instructions are included in the LCD keypad

manual.)
