IDS 816 Installer Manual

IDS 816 700-283-02I Issued September 2009
49
NOTE:
A master user code allows for the programming of other user codes in User Programming Mode.
User Reporting Codes (for 4x 2 and Domestic Reporting)
For all these locations, a two digit hexadecimal code must be programmed. To disable a reporting code
a double zero (00) must be entered into the corresponding location. Note that if one of the above-
mentioned reporting digits is inadvertently omitted or programmed as a zero, the code will not be
reported. The exception to this rule is when using domestic reporting where only the first digit is used.
Sub-location 3 Close Reporting Code
This code is reported when the panel is AWAY ARMED.
Sub-location 4 Stay Close Reporting Code
This code is reported when the panel is STAY ARMED.
Sub-location 5 Open Reporting Code
This code is reported when the panel is disarmed.
Sub-location 6 Siren Cancel Reporting Code
If the siren is sounding and the siren is cancelled using a valid user code, a cancel code will be reported.
Cancelling a silent alarm or silent panic will not cause the cancel siren code to be reported.
14. Programmable Output Options
LOCATIONS 388 – 394 Programmable Output Timing Setup
Locations 388 to 394 allow the installer to setup the timing characteristics of each programmable output
individually.
Location
Output No.
Output Type
388 1 Panel prog. output 1
389 2 Panel prog. output 2
390 3 Panel prog. output 3
391 4 Panel prog. output 4
392 5 Panel prog. output 5
393 6 Zone expander prog. output 2
394 7 Zone expander prog. output 1
