IDS 816 Installer Manual

IDS 816 700-283-02I Issued September 2009
50
Sub-location 1 Output Pulse Time
This sub-location determines the length of time for which an output will pulse.
Value
Delay
Value
Delay
0 (Default)
3 seconds
8
2 minutes
1
10 seconds
9
3 minutes
2
15 seconds
10
4 minutes
3 20 seconds 11 5 minutes
4 25 seconds 12 10 minutes
5 30 seconds 13 15 minutes
6 45 seconds 14 18 minutes
7 1 minute 15 21 minutes
Output Scheduling
Outputs can be scheduled to set and reset at specified times on specific days of the week. To disable
scheduling of an output ensure that all “days” are deselected.
Sub-location 2
Schedule ON Time
Enter the time using “hhmm” format at which the output is to be SET. (MUST be four digits)
Sub-location 3 Schedule ON Days
This bitmapped sub-location determines on which day(s) an output will be set.
LED
Days of the Week
1
Monday
2
Tuesday
3
Wednesday
4 Thursday
5 Friday
6 Saturday
7 Sunday
Sub-location 4 Schedule OFF Time
Enter the time using “hhmm” format at which the output is to be RESET. All four digits must be entered,
include any leading zeros (0100 for 1 am, for example).
Sub-location 5 Schedule OFF Days
This bitmapped sub-location determines on which day(s) an output will be scheduled to RESET.
LED
Days of the Week
1
Monday
2
Tuesday
3 Wednesday
4 Thursday
5 Friday
6 Saturday
7 Sunday
