IDS 816 700-283-02I Issued September 2009
18
7. If you do not wish to change the data within this sub-location, press the [#] hash key. The
READY indicator will continue flashing and the AWAY indicator will turn off.
8. Repeat steps 4 to 7 until all sub-locations at the current location have been programmed as
required.
9. Press the hash [#] key to exit from the current location, the ARMED LED will turn off and the
READY indicator will continue flashing.
10. Repeat steps 2 to 9 until all locations, and their sub-locations, have been programmed as
required.
11. Press the [#] hash key again to exit from program mode (READY LED will stop flashing).
7.4 Programming a Bitmapped Location
1. A bitmapped location allows the installer to program multiple panel features within a single
location or sub-location. This is achieved using the individual zone LEDs to indicate which
features are enabled or disabled.
2. By referring to the appropriate location reference tables, the installer can view the entire selection
of features associated with that location.
3. A zone LED that is on indicates that a feature is enabled. A LED that is off indicates that a feature
is disabled.
4. The installer is able to toggle a selected LED indicator ON or OFF by entering the corresponding
number followed by the [*] star key
5. Once a complete selection of features has been finalised, press the [#] key to leave the
location/sub-location with the state as indicated by the LED.
Example:
Location 40 allows the installer to select up to twelve trouble conditions which may be displayed. By
default, only AC fail and low battery trouble conditions are enabled.
Entering program mode and viewing the contents of Location 40 it will be noted that the zone 1
and zone 5 LEDs will be on. All other zone LED indicators will be turn off.
To enable the Comms Fail Trouble Display (indicated by zone 2 LED) press the [2] key
followed by the [*] star key. A long beep will indicate a valid entry and the zone 2 LED will come on
indicating that Comms Fail Trouble Display has been enabled.
Continue selection (or de-selection) of the desired trouble conditions. Once a final selection
has been made press the [#] hash key to exit the location. The AWAY indicator will turn off and a long
beep will indicate acceptance of a valid data entry.
7.5 Incorrect Data Entries
1. When programming either standard or extended locations any attempt to enter invalid data will
result in an error beep (3 short beeps)
2. In the case of standard locations, the AWAY indicator will remain on after the error beeps. Re-
enter the correct data. There is no need to press the [#] hash key.
3. In the case of extended locations, the AWAY and ARMED indicators will remain on after the error
beeps. Re-enter the correct data. There is no need to press the [#] key.
7.6 Programming Location Summary
A detailed description of each location and its options follows.
