IDS 816 Installer Manual

IDS 816 700-283-02I Issued September 2009
31
NOTE:
When connecting any device with a high current requirement to a programmable output a suitable relay
must be used. DO NOT connect such devices directly to the programmable outputs as this may damage
the output circuitry.
LOCATIONS 70-87 Event Driven Programmable Outputs
Table 7 : Event Driven Programmable Outputs
Loc.
Event
Output
Default Action
70 AC fail programmable output Disabled
71
AC restore programmable output
Disabled
72
Low battery programmable output
Disabled
73 Battery restore programmable output Disabled
74 Auto test programmable output Disabled
75 Download programmable output Disabled
76 Siren trouble programmable output Disabled
77 Aux 12V trouble programmable output Disabled
78 Keypad fuse programmable output Disabled
79 485 device tamper programmable output Disabled
80 485 bus failure programmable output Disabled
81
Box tamper programmable output
Disabled
82
Dedicated panic programmable output
1
Pulse high [2]
83
Communication fail programmable output
Disabled
84 Phone line tamper programmable output Disabled
85 Phone line restore programmable output Disabled
86 RF jamming programmable output Disabled
87
RF jamming restore programmable
output
Disabled
LOCATIONS 95 – 96 Function Driven Programmable Outputs
Table 8 : Function Driven Programmable Outputs
Summary of System function Driven Programmable outputs
Loc.
Function
Output
95 Fire sensor power programmable output Disabled
96 Dual reporting programmable output Disabled
