IDS X Series Training Manual

IDS X-Series Training v2.7 | Reporting Codes
57
Location 300 Global Reporting
Location Type: Extended
Location 301 Global Reporting
Location Type: Extended
Location 302 Global Reporting
Location Type: Extended
Sub Loc.
Description
Explanation
1
Bus Device Tamper
When a device that is connected to the keypad bus registers a tamper this
code is sent to the alarm company.
2
Bus Device Tamper
Restore
When the device on the bus registers that the tamper condition has been
restored it will send this code.
3
Bus Peripheral
Communication Fail
When a device that has been registered on the bus stops communicating
with the control panel this code is sent.
4
Bus Peripheral
Communication
Restore
Once the communication between the control panel and the missing device
is corrected a restoral is sent to the alarm company.
5
Bus Peripheral
Power/Battery Low
A device that has the ability to monitor its power detects that its power is low
a message can be sent.
6
Bus Peripheral
Power/Battery
Restore
Once the power is restored a signal alerting the monitoring company can be
sent.
7
Wireless Detector
Battery Low
Wireless devices monitor their batteries and when a battery needs changing
this low battery code is sent.
8
Wireless Detector
Battery Restore
After changing the battery a restoral is sent.
Sub-Loc
Description
Explanation
1
AC Fail
This reporting code is sent when the main electrical supply has failed and
the system is running on the backup battery.
2
AC Restore
This reporting code is sent when the main electrical supply is restored.
3
Communication Fail
This reporting code is sent when the communication dial attempts have
been exhausted.
4
Communication Restored
When communication is restored this code is sent.
5
Phone Line Tamper
If the phone line is tampered with and the line voltage goes missing and
this code is sent.
6
Phone Line Restore
When the line voltage is restored this reporting code is sent alerting the
security company.
7
Siren Tamper
The X-Series alarm panel monitors the siren and if it goes missing a signal
is sent.
8
Siren Tamper Restore
Once the siren has been restore the security company is alerted.
Sub-Loc.
Description
Explanation
1
Battery Low
When the system detects that the battery voltage has reached 10.5V this
code is sent to warn the company that it is about to switch off.
2
Battery Restore
Once charged a restore will be sent to confirm the battery is charged.
3
Auxiliary 12V Fuse Failed
If the fuse protecting the auxiliary 12V output goes faulty this code is sent
to alert the security company.
4
Auxiliary 12V Fuse
Restored
When the auxiliary fuse fault is corrected a restore is sent.
5
Installer Reset Required
If this option is enabled in location 211 to 218 and the alarm is tripped in
that partition, the alarm can’t be armed until the installer code is entered.
6
Installer Reset Restored
Once the installer code has been entered after an alarm has tripped a
restoral will be sent.
7
Box Tamper
The alarm panel has a connector to monitor a tamper switch so that the
alarm box can’t be opened without notifying the security company.
8
Box Tamper Restore
When the box is closed a restore is sent.
