IDS X-Series Training v2.7
Locations 501 - 564 Zone Split Reporting
LED
Factory
Default
Default 6
Action
LED
On/Off
Reporting Pair
1
ON
ON
Zone alarm reporting
9
OFF
Telephone module 1
2
OFF
OFF
Zone alarm restore reporting
10
OFF
Telephone module 1
3
OFF
OFF
Zone bypass reporting
11
OFF
Telephone module 1
4
OFF
OFF
Zone force arm reporting
12
OFF
Telephone module 1
5
OFF
OFF
Zone tamper reporting
13
OFF
Telephone module 1
6
OFF
OFF
Zone tamper restore reporting
14
OFF
Telephone module 1
7
OFF
OFF
Zone swinger shutdown reporting
15
OFF
Telephone module 1
8
OFF
OFF
Zone swinger shutdown restore
reporting
16
OFF
Telephone module 1
Location 571 Global Split Reporting 1
LED
Factory
Default
Default 6
Action
LED
On/Off
Reporting Pair
1
ON
OFF
Enable AC fail reporting
9
OFF
Telephone module 1
2
OFF
OFF
Disable communication fail reporting
*
10
OFF
Telephone module 1
3
ON
OFF
Enable telephone line tamper
reporting
11
OFF
Telephone module 1
4
ON
OFF
Enable siren fail reporting
12
OFF
Telephone module 1
5
ON
OFF
Enable panel low battery fail
reporting
13
OFF
Telephone module 1
6
ON
OFF
Enable aux 12V fuse fail reporting
14
OFF
Telephone module 1
7
OFF
OFF
Installer Reset Required
15
OFF
Telephone module 1
8
ON
OFF
Enable box tamper reporting
16
OFF
Telephone module 1
Location 572 Global Split Reporting 2
LED
Factory
Default
Default 6
Action
LED
On/Off
Reporting Pair
1
ON
OFF
Enable bus-wired peripheral tamper
reporting
9
OFF
Telephone module 1
2
ON
OFF
Enable bus-wired peripheral fail
reporting
10
OFF
Telephone module 1
3
OFF
OFF
Disable bus-wired peripheral low
battery reporting *
11
OFF
Telephone module 1
4
ON
OFF
Wireless Detector Battery Low
12
OFF
Telephone module 1
5
OFF
OFF
Wireless Detector Supervision fail
13
OFF
Telephone module 1
6
OFF
OFF
Wireless Receiver Signal Jammed
14
OFF
Telephone module 1
7
OFF
OFF
Wireless Detector RSSI Low
15
OFF
Telephone module 1
8
ON
OFF
AC Restored
16
OFF
Telephone module 1
