16
3.3 Assemble the Cutting Beam
Beam Block slider
Pay attention:
Keep balance from rear side when assembling the cutting beam, carefully take out the plug in the slider,
put the cutting beam onto the side beams, make sure that the pen holder faces to the photoelectric plate.
After assembly, put the block slider back and then tighten the screws.
