7. Operation
7.1 Preparation

Before starting, make sure there is nobody on the working area.

Be sure to check the platform before starting, make sure no sundry in the X/Y chain during the process.

Check whether there is lubricating oil in Y guide.

Check whether the air pressure reaches 0.6Mpa.

Check whether it is correct with tools and installation.
7.2 Steps

Power on.
 Wait for machine initialization. Procedures: Cutting head height initialization, X/Y direction initialization,
cutting head rotation initialization, and cutting head move to start point.
 To avoid the blade cut the felt, please adjust the depth of tools。
 Put the materials on the table, start the vacuum pump which sucks and fixes materials on the table. If the material
is breathable, a piece of plastic film is needed to be covered on the material.
 Open “IECHO Digital cutting system”, import the files (DXF or PLT). The system will process the analysis of
outline and the definition of cutting tool and cutting type.

Set cutting parameter (Attention: Special parameter must be set under ERROR status in CutterSever then
use “Shift+ctrl+alt+M”)
 Start the vacuum pump, move the cutting head, select laser point in CutterServer, preview the cutting area. If
the material is not in the preview area or exceed, please adjust the material.
 Click cutting icon after confirmation, the machine will start to cut.

After finishing cutting, please turn off the power and other relevant switch.
