IECHO TK4S - 1.4 Technical Parameters

2
1.4 Technical Parameters
Definition
Parameter
Model
TK4S 2521（TK4S 2521 is just one model, more dimension is available）.
Cutting Area
2500*2100 mm (98.4 inch *82.6 inch)
Machine Dimension
3340*3000*1273 mm (131.4 inch *118.1 inch *50.1 inch)
Weight
1550 kg
Vacuum Zones
3 - 24
Max Speed
1500mm/s (59inch/s)
Accuracy
0.1mm
Max Cutting Thickness
50mm (1.96 inch)
Modules
Can be installed up to 3 cutting heads
File Formats
DXF
、
PLT
、PDF、HPG、HPGL、TSK、BRG、XML、CUT、OXF、ISO、
AI、PS、EPS
Interface
Serial Port / USB Port
Adsorption
Vacuum Pump
Power
Single-phase 220V / 2KW
（
exclude the power of feeder
）
Three-phase 220V/380V 5
.5KW/7.5KW*n (n is the quantity of vacuum zone,
exclude the power of feeder
）
Power Requirement
220V/50/60HZ
、
380V/50/60HZ (Three-phase five-wire system)
Air Pressure Requirement
0.6~0.85MPa，
Dry compressed air
Operating Environment
Temperature
：0℃-40℃ ； Humidity：20%-80%RH
Storage Temperature
- 20 to + 55 °C
