IEI Technology ICE-BT-T6 User Manual

ICE-BT-T6 COM Express Module
Page 3
1.2 Model Variations
The model variations for the ICE-BT-T6 series are listed in Table 1-1.
On-board SoC Memory
Model
Name Clock Speed # of Cores L2 Cache Max TDP Slot #
ICE-BT-T6-J19001 Intel® Celeron® J1900 2.0 GHz 4 2 MB 10 W Two
ICE-BT-T6-N29301 Intel® Celeron® N2930 1.83 GHz 4 2 MB 7.5 W Two
ICE-BT-T6-N28071 Intel® Celeron® N2807 1.58 GHz 2 2 MB 4.3 W One
ICE-BT-T6-E38451 Intel® Atom™ E3845 1.91 GHz 4 2 MB 10 W Two
ICE-BT-T6-E38271 Intel® Atom™ E3827 1.75 GHz 2 1 MB 8 W Two
ICE-BT-T6-E38261 Intel® Atom™ E3826 1.46 GHz 2 1 MB 7 W Two
ICE-BT-T6-E38251 Intel® Atom™ E3825 1.33 GHz 2 1 MB 6 W One
ICE-BT-T6-E38151 Intel® Atom™ E3815 1.46 GHz 1 512 KB 5 W One
Table 1-1: Model Variations
1.3 Features
Some of the ICE-BT-T6 COM Express module features are listed below:
 Complies with COM Express Type 6 form factor
 On-board 22nm Intel® Atom or Celeron® processor
 Two/One 204-pin 1066/1333 MHz dual-channel unbuffered DDR3L SDRAM
DIMM slots support up to a total of 8 GB of memory
 Optional on-board 4 GB SSD
 Supports analog CRT (VGA), DisplayPort, HDMI and LVDS
 Supports USB 3.0, SATA 3Gb/s and GbE
 RoHS compliant

IEI Technology ICE-BT-T6 Specifications

General

Brand	IEI Technology
Model	ICE-BT-T6
Category	Motherboard
Language	English
