IEI Technology ICE-BT-T6 User Manual

ICE-BT-T6 COM Express Module
Page 8
ICE-BT-T6
Watchdog Timer
Software programmable supports 1~255 sec. system reset
Storage
Two SATA 3Gb/s (signal to baseboard)
Optional on-board 4 GB SSD (SATA port1)
Display
(Signal to Baseboard)
One VGA (up to 2560 x 1600)
One DDI 1 (DP/HDMI, max. resolution: 2560x1600/1920x1080)
One DDI 2 (24-bit dual-channel LVDS, optional via CH7511B)
One LVDS: 18/24-bit dual-channel LVDS by CH7511B DP to LVDS
converter (up to 1920x1200 @ 60Hz)
Expansions
(Signal to Baseboard)
Five PCIe x1 (two from SoC, three from PLX PEX8605 switch IC)
I/O Interfaces
(Signal to Baseboard)
Seven USB 2.0
Four USB 3.0 (via one-to-four USB 3.0 hub)
Two RS-232 (TX and RX from EC)
HD Audio
8-bit GPIO
SMBus
I
2
C
LPC
SPI
Power Consumption
+12V @ 0.54 A , Vcore_12V @ 0.95 A (2.0 GHz Intel® Celeron®
J1900 CPU with one 8 GB 1333 MHz DDR3L memory)
Operating
Temperature
-20ºC ~ 60ºC
Storage Temperature
-30ºC ~ 70ºC
Operating Humidity
5% ~ 95% (non-condensing)
Dimensions
125 mm x 95 mm
Weight (GW/NW)
600 g/200 g
Table 1-2: ICE-BT-T6 Specifications
