IEI Technology ICE-BT-T6 User Manual

ICE-BT-T6 COM Express Module
Page 17
Pin No. Description Pin No. Description
A9
GBE0_MDI1-
B9
LPC_DRQ1#
A10
GBE0_MDI1+
B10
LPC_CLK
A11
GND1
B11
GND16
A12
GBE0_MDI0-
B12
PWRBTN#
A13
GBE0_MDI0+
B13
SMB_CK
A14
GBE0_CTREF
B14
SMB_DAT
A15
SUS_S3#
B15
SMB_ALERT#
A16
SATA0_TX+
B16
SATA1_TX+
A17
SATA0_TX-
B17
SATA1_TX-
A18
SUS_S4#
B18
SUS_STAT#
A19
SATA0_RX+
B19
SATA1_RX+
A20
SATA0_RX-
B20
SATA1_RX-
A21
GND2
B21
GND17
A22
RSVD
B22
RSVD
A23
RSVD
B23
RSVD
A24
SUS_S5#
B24
PWR_OK
A25
RSVD
B25
RSVD
A26
RSVD
B26
RSVD
A27
BATLOW#
B27
WDT
A28
ATA_ACT#
B28
RSVD
A29
AC/HD_SYNC
B29
AC/HD_SDIN1
A30
AC/HD_RST#
B30
AC/HD_SDIN0
A31
GND3
B31
GND18
A32
AC/HD_BITCLK
B32
SPKR
A33
AC/HD_SDOUT
B33
I2C_CK
A34
BIOS_DISABLE#
B34
I2C_DAT
A35
RSVD
B35
RSVD
A36
USB6-
B36
RSVD
A37
USB6+
B37
RSVD
A38
USB_6_7_OC#
B38
USB_4_5_OC#
A39
USB4-
B39
USB5-
A40
USB4+
B40
USB5+
