1.6.3. INTERIOR VIEW OF THE PRINTER
Opening the cover provides access to the following
components:
Paper path, which is mainly comprised of:
▪ Ejector/document holder module (1)
▪ Separator (cutter/burster) module (2)
▪ Printing module (6) with printhead (7)
▪ Channel selector (5), (four channels), with a media
sensor for each channel (4)
Power supply unit (3)
