1.6.2. EXTERIOR REAR VIEW
The rear of the IER 560 COMBO Printer includes:
 Connector panel including:
▪ RS232 serial port (10), (BT: bag tag label printing
applications)
▪ RS232 serial port (11), (BP: boarding pass printing
applications)
▪ USB host port (8), (host system)
▪ RJ45 Ethernet port (9)
 Transport handle (1).
 Cover locking latch (2).
 Paper channel selector with a basic configuration that
offers:
▪ Upper channel: U (3), (BT: Loading of bag tag media)
▪ Mid-upper channel: MU (4), (BT: Loading of bag tag
media)
▪ Mid-lower channel: ML (5), (BP: Loading of boarding
pass media)
▪ Lower channel: L (6), (BP: Loading of boarding pass
media)
 Power connector (7).
