6.2. PROCEDURES PRIOR TO PERIODIC MAINTENANCE
6.2.1. GENERAL DUSTING
To perform this, IER recommends that only the air
can provided in the kit be used since its gas has
been tested and approved as non-flammable and
non-explosive. IER disclaims all liability for
incidents arising from the use of another product.
DO NOT USE THE AIR CAN WHEN THERE IS
ONLY LITTLE AIR LEFT; THE CAN CONTAINS
MOSTLY PROPELLANT, WHICH IS HIGHLY
FLAMMABLE.
Follow the safety precautions on the can as well as those
indicated above when using the air can supplied in the
cleaning kit to remove paper chaff and to perform a general
dusting of the printer by directing the air flow (see Figure 6.1
and Figure 6.2):
inside the media insertion channels,
toward the media sensors
toward the different sensors located on
the cutter/burster module: the oscillating
synchronization sensor, the blade position
sensor and the paper output sensor
to the cutter blade and counter blade, as
well as to the internal parts of the
cutter/burster module
under the paper guide and the print
mechanism
above and under the platen
inside the ejection/document holder
module
into the paper output slot of the front
panel
