3.2. BAG TAG MEDIA
Note: The installation and loading of blank roll type bag tag
media is performed in the mid-upper channel (MU
channel) and the upper channel (U channel) of the printer
(see page 22).
3.2.1. INSTALLATION OF BLANK MEDIA
3.2.1.1. Media Installation Procedure

 Follow the instructions below to install and
position the blank media roll(s):
IMPORTANT: Install the roll(s):
▪ parallel to the printer
▪ centered in relation to the insertion slot
▪ with the heat-sensitive side of the media
facing up
