IER 560 COMBO PRINTER
User Guide
Page 21
N0C902A Rev. 2
Sept. 14, 2010
Ce document est la propriété d’IER et ne doit pas être reproduit ou communiqué sans autorisation écrite.
This document is the property of IER and may not be reproduced or communicated
without prior written authorization
12
11 10
9
14
13
5
7
8
6
5 – Control panel with display
6 – Display
7 – RECEPTION indicator
8 – ONLINE indicator
9 – Mode key
10 – TEST key
11 – MENU key
12 – RESET key
13 – ALARM indicator
14 – CHECK DISPLAY indicator
Figure 1.8
Control Panel
