The control panel with display (5) consists of:
4-line/20-character LCD display (6)
Four keys:
▪ ONLINE/ENTER key (9), which enables switching
from one mode to another ( Offline /
Online )
▪ TEST / - key (10), which is deactivated in Online
mode
▪ MENU / +key (11), which is deactivated in Online
mode
▪ RESET EJECT/EXIT key (12), which allows warnings
and errors to be acknowledged, or the printer to be
reset
Four indicators:
▪ ALARM indicator (13)
▪ CHECK DISPLAY indicator (14)
▪ RECEPTION indicator (7)
▪ ONLINE indicator (8)
The activation and behavior of the four indicators reflect
the printer's operational status (see page 50) and the
occurrence of printing errors (see page 43).
Sound alarm that warns the user of an event.
