Parameters of the inputs
7652
ENABLE BOOL := FALSE TRUE: Any desired address available
FALSE: Fixed address
CHANNEL BYTE CAN interface (1...n) depending on the device
IndustryGroup
(optional use of the parameter)
BYTE = 0xFF industry group = industry group of the device
permissible values = 0...7
255 = 0xFF = filter for all
VehicleSystemInstance
(optional use of the parameter)
BYTE := 0xFF instance of the vehicle system
permissible values = 0...15 = 0x00...0x0F
255 = 0xFF = filter for all
VehicleSystem
(optional use of the parameter)
BYTE := 0xFF vehicle system
permissible values = 0...127 = 0x00...0x7F
255 = 0xFF = filter for all
nFunction
(optional use of the parameter)
WORD := 0xFFFF function of the device
permissible values = 0...255 = 0x0000...0x00FF
65 535 = 0xFFFF = filter for all
FunctionInstance
(optional use of the parameter)
BYTE := 0xFF instance of the function
permissible values = 0...31 = 0x00...0x1F
255 = 0xFF = filter for all
ECUInstance
(optional use of the parameter)
BYTE := 0xFF instance of the control device
permissible values = 0...7
255 = 0xFF = filter for all
ManufacturerCode
(optional use of the parameter)
WORD := 0xFFFF manufacturer code (must be requested from SAE)
permissible values = 0...2047 (2
11
-1) = 0x0000...0x07FF
65 535 = 0xFFFF = filter for all
IdentityNumber
(optional use of the parameter)
DWORD := 0xFFFF FFFF serial number of the device (should not be overwritten)
permissible values = 0...2047 (2
11
-1))
4 294 967 295 = 0xFFFF FFFF = filter for all
>
Parameters of the outputs
7661
RESULT BYTE feedback of the function block
(possible messages → following table)
Possible results for RESULT:
Value
dec | hex
Description
0 00 FB is inactive
1 01 function block execution completed without error
8 08 function block is active
242 F2 Error: setting is not possible
