ifm Programming Manual ecomatmobile BasicController (CR0403) Runtime System V03.02 2015-04-01
ifm function elements ifm function elements for the device CR0403
>
GET_SW_VERSION
14763
= get software version
Unit type = function block (FB)
Unit is contained in the library ifm_CR0403_Vxxyyzz.LIB
Symbol in CODESYS:
>
Description
14765
GET_SW_VERSION provides information on the software in the device:
• BasicSystem version
• bootloader version
• SIS version
• IEC application program version
• IEC user flash version
>
Parameters of the inputs
14766
Parameter
Data type
Description
ENABLE
BOOL
TRUE: execute this function element
FALSE: unit is not executed
> Function block inputs are not active
> Function block outputs are not specified
>
Parameters of the outputs
14767
Parameter
Data type
Description
BS_VERSION STRING(24) Basic system version
BL_VERSION STRING(24) Bootloader version
SIS_VERSION STRING(24) SIS version (SIS = System Information Service)
IEC_VERSION STRING(24) IEC application program version
USER_VERSION STRING(24) IEC user flash version
RESULT BYTE feedback of the function block
(possible messages → following table)
Possible results for RESULT:
Value
dec | hex
Description
0 00 FB is inactive
1 01 FB execution completed without error – data is valid
