ifm Programming Manual ecomatmobile BasicController (CR0403) Runtime System V03.02 2015-04-01
System description Hardware description
>
3.2.3 Outputs (technology)
Protective functions of the outputs ...................................................................................................... 18
Output group Q0 (OUT0, OUT1) ......................................................................................................... 20
Output group Q1 (OUT2, OUT3, OUT8, OUT9) .................................................................................. 22
Output group Q2 (OUT4...OUT7) ........................................................................................................ 23
Output group Q3 (OUT10, OUT11) ..................................................................................................... 24
14093
>
Protective functions of the outputs
15248
The outputs of this device are protected against overload and short circuit within specific ranges.
→ data sheet
>
Definition: overload
15249
Overload can only be detected on an output with current measurement.
Overload is defined as ...
"a nominal maximum current of 12.5 %" according to the data sheet.
>
Definition: short circuit
15644
A short circuit can be detected on all outputs with diagnostic capabilities and is defined as follows:
A short circuit is defined as ...
"a drop of the output voltage below 93.5% (± 2.0%) of the corresponding supply voltage."
> A ground fault can only be detected in case of output = TRUE.
