ifm Programming Manual ecomatmobile BasicController (CR0403) Runtime System V03.02 2015-04-01
System description Hardware description
>
Output group Q2 (OUT4...OUT7)
15235
These outputs are a group of multifunction channels.
These outputs provide several function options (each output separately configurable):
• binary output, plus switching (BH)
• analogue output with Pulse Width Modulation (PWM)
• These outputs are not able for diagnosis.
→ chapter Possible operating modes inputs/outputs (→ page 207)
► Configuration of each output is made via the application program:
→ FB OUTPUT (→ page 180)> input MODE
PWM output: → FB PWM1000 (→ page 182)
► For the limit values please make sure to adhere to the data sheet!
