Parameters of the outputs
14980
Parameter
Data type
Description
REDSTOPLAMP BOOL red stop lamp (for older projects only)
TRUE: OFF
FALSE: ON
AMBERWARNINGLAMP BOOL Amber warning lamp (for older projects only)
TRUE: OUT
FALSE: ON
PROTECTLAMP BOOL protect lamp (for older projects only)
TRUE: OFF
FALSE: ON
NUMBER BYTE number of the DTCs received (0...8)
SPN WORD Suspect Parameter Number
FMI BYTE Failure Mode Indicator
permissible values = 0...31 = 0x00...0x1F
SPN_CM BOOL conversion method
OC BYTE occurrence count
RESULT BYTE feedback of the function block
(possible messages → following table)
MIL_FC BYTE Status of the electronic component:
Malfunction indicatation light status and flash code:
0 = off
1 = on
2 = flash slowly
3 = flash quickly
REDSTOPLAMP_FC BYTE Status of the electronic component:
red stop light status and flash code:
0 = off
1 = on
2 = flash slowly
3 = flash quickly
AMBERWARNINGLAMP_FC BYTE Status of the electronic component:
Yellow warning light status and flash code:
0 = off
1 = on
2 = flash slowly
3 = flash quickly
PROTECTLAMP_FC BYTE Status of the electronic component:
protection light status and flash mode:
0 = off
1 = on
2 = flash slowly
3 = flash quickly
Possible results for RESULT:
Value
dec | hex
Description
0 00 FB is inactive
1 01 FB execution completed without error – data is valid
8 08 FB is active – no data was received
242 F2 Error: setting is not possible
