3.4.2 Functionality
In the IO-Link SIO mode, the device has the same functionality as a stand-alone
device� The measured value is also displayed�
Additionally, the device converts the measured current and transmits the value via
IO-Link connection to the PLC�
3.4.3 IO Device Description (IODD)
You will find the IODDs necessary for the configuration of the IO-Link device and
detailed information about process data structure, diagnostic information and
parameter addresses at:
www�ifm�com
4 Operating and display elements
3
2
1
1: Push rings (pushbuttons)
2: LEDs
3: Display
Here the Enter button is shown pressed, as
an example [●].
