Customer locking
If [C�Loc] is displayed when an attempt is made to modify a parameter
value, an IO-Link communication is active (temporary locking)�
Software locking
If [S�Loc] is displayed, the sensor is permanently locked via software� This
locking can only be removed with an IO-Link parameter setting software�
9.3.2 Timeout
If no button is pressed for 30 s during parameter setting, the device returns to the
operating mode with the unchanged value�
9.3.3 Change from the main menu to the extended functions menu
► Press [●] to get to the menu.
► Press [▲] or [▼] until [EF] is displayed.
► Press [●].
> The first parameter of the extended functions menu is displayed ([rES])�
9.3.4 Numerical entries with [▼] or [▲]
► Press [▲] or [▼] for minimum 2 s.
> After 2 s:
- value is changed continuously by keeping the button pressed�
- value is changed incrementally by pressing the button once�
Value is incrementally reduced with [▼] and increased with [▲].
