IFM Electronic DP2200 - Scale Drawing; Technical Data

28
10 Scale drawing
31
24
30
M12 x 1
M12 x 1
63
Dimensions [mm]
11 Technical data
Operating voltage DC [V] 18���30
Nominal voltage DC [V] 24
Power consumption [W] ≤ 1
Auxiliary supply for sensor [V] from the operating voltage
Current for sensor [mA] ≤ 800
Sensor type sensor with analogue current output: 4…20
mA
2-wire or 3-wire sensor
Accuracy [% FS] 0�5
Protection rating IP 67 *
Ambient temperature [°C] -25…60 **
Storage temperature [°C] -25…70
