12 Fault correction
Display LED Error Fault correction
I Power
OFF Supply voltage too low� Check/correct the supply
voltage (→ 6) and (→ 11)�
SC1 -- Excessive current at switching
output OUT1�
Check switching output OUT1
for short-circuit or excessive
current� Remove the fault�
C�Loc -- -- Parameter setting via
pushbuttons locked due to
active IO-Link transmission�
Wait until parameter setting via
IO-Link is finished�
S�Loc -- -- Parameter setting via
pushbuttons disabled by
software�
Unlocking only possible via
IO-Link interface/IO-Link
parameter setting software�
Loc -- -- Parameter setting via
pushbuttons disabled�
Unlock buttons (→ 9.3.1)�
OL -- Process value too high
(measured current > 21 mA)�
Check connected sensor and
current range (→ 4.3.1)�
Check the setting for internal or
external analogue termination
for OUT2 (→ 8.4.2)�
UL -- Process value too low
(measured current < 3�6 mA)�
nPrb -- No sensor connected to the
analogue input�
Legend:
off
on
flashing
-- any
