4.3.1 Representation of the measured current value
21 [mA]3�83�60�30�10 20�5
nPrb UL OL
3
2
1
Input current
Silent
events
3600-21000 μA
Process
data
-32760 3276032764
display
3�60���21�00 mA "UL" "OL""nPrb"
IO-Link
4
1: No measured data
2: Input current below the range (-)
3: Input current above the range (+)
4: Displayed message or displayed value�
The input current is displayed here without scaling�
nPrb:
UL:
OL:
No sensor
Process value too low
Process value too high
Hysteresis range
5 Installation
If required, the device can be fixed with a mounting clip�
Mounting clip (fasten with M4 screw or
cable ties)
Mounting clip with display attached
The mounting clip is not supplied with the device�
