8.4 Parameters of the extended functions (EF)
8.4.1 rES ─ restore factory setting
Resets all parameters to the factory setting (→ 14)�
► Select [rES]�
► Press [●].
► Press and hold [▲] or [▼] until [----] is displayed.
► Briefly press [●].
8.4.2 A.trm ─ analogue termination for OUT2
• [OFF] = OUT2 is externally connected, e�g� to the analogue input of another
device�
• [On] = OUT2 is not connected and the current path is terminated internally�
Note the following for proper current measurement and evaluation:
If the internal analogue termination is set to [On], output OUT2 must not be
connected�
8.4.3 ou1 ─ output function for OUT1
Switching signal for the current limits�
See also (→ 8.3.1) and (→ 8.3.2)�
• [Hno] = hysteresis function / normally open
• [Hnc] = hysteresis function / normally closed
• [Fno] = window function / normally open
• [Fnc] = window function / normally closed
8.4.4 dS1/dr1 ─ switching delay/switch-off delay for OUT1
Value: 0�0���50�0 s (0�0 = delay time is not active)
8.4.5 ScAL ─ scaling of the displayed value
The setting acts like a multiplier for the parameters [C�ASP/C�AEP]�
• [OFF] = measured current value is not scaled�
• [cccc] = scaling without decimal place (x 0001)�
• [ccc�c] = scaling with 1 decimal place (x 000�1)�
• [cc�cc] = scaling with 2 decimal places (x 00�01)�
• [c�ccc] = scaling with 3 decimal places (x 0�001)�
