14 Parameter list and factory settings
Parameter Factory
settings
User settings
SP1/FH1 Set point OUT1 6�00
rP1/FL1 Reset point OUT1 5�00
A.trm Analogue termination OUT2 On OFF
On
ou1 Output function OUT1 Hno Hno
Hnc
Fno
Fnc
dS1 Switching delay OUT1 0�0 s
dr1 Switch-off delay OUT1 0�0 s
ScAL Scaling value OFF OFF
cccc
ccc�c
cc�cc
c�ccc
C.ASP Customised analogue start point ----
C.AEP Customised analogue end point ----
C.uni * Customised unit mA
coLr Colour display rEd rEd
GrEn
r1ou
G1ou
r-cF
G-cF
cFH Colour change, upper limit value 20�00
cFL Colour change, lower limit value 4�00
diS Display refresh rate d2 (200 ms) OFF
d1 (50 ms)
d2 (200 ms)
d3 (600 ms)
Lo Lower measured input value ----
Hi Upper measured input value ----
dAP Damping of the measured analogue
value
0�060 s
(= 60 ms)
*) can only be configured via IO-Link and parameter setting software (→ 8.5)
