29
UK
Max� perm� relative humidity [%] 90 (31 °C)
linearly decreasing to 50 (40 °C)
non condensing
Maximum operating altitude [m] 2000 above sea level
Permissible air pressure [hPa] 750���1060
Connectors M12 connector, 4-pole
M12 socket, 5-pole
*) With screwed and firmly tightened M12 connectors
(→ 6 Electrical connection)
**) For IO-Link operating mode and turned off display: -25���70 °C
11.1 IO-Link device
Transmission type COM2 (38�4 kbaud)
IO-Link revision 1�1
SDCI standard IEC 61131-9
IO-Link device ID 610 d / 00 02 62 h
SIO mode yes
Input load current at input C/Q
to V0 (ILL)
[mA] 50
Required master port type A
Process data analogue IN: 1
Process data binary IN: 1
Min� process cycle time [ms] 3�2
11.2 Approvals/standards
EC declarations of conformity, approvals etc� can be downloaded at:
www�ifm�com
