28
9.2 Explanation of the menu
SP1/rP1 Upper / lower limit value for the level at which OUT1 switches�
FH1/FL1 Upper / lower limit for the acceptable range (monitored by OUT1)�
OU1 Output function for OUT1:
switching signal for level limit value� Hysteresis or window function, normally
closed or normally open
OU2 Output function for OUT2:
Analogue signal for the current level, 4…20 mA / 0���10 V or
20…4 mA / 10���0 V�
OFS Offset value for level measurement
EF Extended functions / opening of menu level 2�
rES Restore factory setting�
dr1 Switch-off delay for OUT1� The menu item is only active if OU1 = Hno or
Hnc�
FOU1 Response of OUT1 in case of a fault�
FOU2 Response of OUT2 in case of a fault�
dFo Delay time for the outputs to pass into the safe state�
ASP Analogue start point for level: Measured value at which the analogue start
value is provided� The analogue start point is
set with parameter [OU2]�
AEP Analogue end point for level: Measured value at which the analogue end
value is provided� The analogue end value is
set with parameter [OU2]�
Uni Unit of measurement (cm or inch)�
SELd Type of indication�
LEnG Probe length�
MEdI Medium to be detected�
Prob Type of probe used (single probe or coaxial probe)� The menu item is only
active if MEdI = HIGH�
Output function for OUT2:
analogue signal for current level, 4…20 mA or 20…4 mA
