24
Explanation of the menu9.2
SP1/rP1 Upper / lower limit value for the level at which OUT1 switches�
FH1/FL1 Upper / lower limit for the acceptable range (monitored by OUT1)�
OU1 Output function for OUT1:
Switching signal for the level limit values: hysteresis function [H ��] or •
window function [F ��], either normally open [� no] or normally closed [� nc]�
OU2 Output function for analogue output (OUT2): current or voltage output:
I = 4���20 mA / U = 0���10 V�
OFS Offset value for level measurement
EF Extended functions / opening of menu level 2�
rES Restore factory settings�
dr1 Switch-off delay for OUT1� The menu item is only active if OU1 = Hno or
Hnc�
FOU1 Response of OUT1 in case of a fault�
FOU2 Response of OUT2 in case of a fault�
ASP Analogue start value for the level; measured value at which 4 mA / 0 V is
provided�
AEP Analogue end value forthe level; measured value at which 20 mA / 10 V is
provided�
dFo Delay time for switching response OUTx�
Uni Unit of measurement (cm or inch)�
SELd Type of indication�
LEnG Length of the rod�
MEdI Medium to be detected�
Prob Type of probe used (single probe or coaxial probe)� The menu item is only
active if MEdI = HIGH�
